Shield 1500

LED Powered Advanced Oxidation for Water Treatment

The patented Puralytics ® process employs LEDs to excite our proprietary nanotechnology mesh which drives light-activated treatment processes including an advanced oxidation process. The Shield achieves advanced disinfection, detoxification and contaminant degradation; it can be used in industrial treatment settings, manufacturing process or waste treatment. Emerging contaminants (personal care products & pharmaceuticals), herbicides and pesticides, pathogens (bacteria, virus, protozoa) and industrial chemicals (petrochemicals, toxins) are all destroyed in the treatment process. Multiple Shields may be used to achieve volume or treatment level requirements.

download (1).jpg
download (3).jpg
download (2).jpg

Unit Specifications

• Water Recovery: 100%
• Water Production: 0.5-3.9 L/min | 200–1500 gallons per day 0.3- 1 GPM
• Pressure Drop: 2–7 psi @ 200-1500 gpd
• Power Consumption: 570 Watts
• Power Input: 100-240V, 50-60Hz
• Ambient Operating Temp: 5–40°C | 41–104°F
• Dim: 91 x 32 x 45 cm | 36 x 12 x 18 inches
Weight: 24.5 kgs | 60 lbs


• Small footprint
• Flexible configuration (modular and scalable)
• Easy integration and operation
• Low pressure drop
• Low maintenance requirements
• No chemical additives



Puralytics technology effectiveness that provides wide range of contaminants removed. All data based on Single Pass tests in the Shield Series. Note: Shields can be used in parallel or in series to improve removal rates and capacity treated


Misc. Organic Compound Removal

Volatile Organic Compound (VOC) Removal

*Tested in-house. All other testing and analysis by third-party labs

Pesticide (herbicide/insecticide) Removal

*All testing and analysis by third-party labs.

Metals Removal

*All testing and analysis by third-party labs.

Microbiological Removal- Single Pass Shield Series
